FA1014-NP/C/T

10.1 inch Capacitive Touch Monitor

- Multi-touch capacitive screen,
- Lux auto brightness,
I- ntegrated dustproof front panel,
I- /O control interface,
- HDMI, DVI, VGA & AV inputs,
- High contrast: 800:1,
- High brightness: 350cd/m².
Features:
  • 10-point touch capacitive screen(OS: Windows 7 or above).
  • Lux auto brightness,
  • Integrated dustproof front panel,
  • I/O control interface,
  • High contrast: 800:1,
  • High brightness: 350cd/m².

Wide Viewing Angles (IPS Panel)

170° horizontal & 170° vertical wide viewing angles, it's available for people viewing from different angles with the same visual effect.

?


Bigger size, larger view.

10.1" IPS display panel with 1280×800 native resolution,?twice viewing area than 7” display.?

?


Capacitive Touch Panel (FA1014-NP/C/T with touch， FA1014-NP/C without touch)

Support 10-point allows people flip and zoom in/out picture via fingers, High precision fast response, and have a longer life, Better transmittance.?

?

zoom out? ? ? ? ? ? ? ?? ? ? ? ? ? ? ? ?? ? ? ? ? ? ? ? ?? ? ? ? ? ? ? ? ?? ? ? ? ? ? zoom in


Lux Auto Brightness (optional)
A light sensor designed to detect ambient lighting conditions adjusts the panel's brightness automatically, which makes viewing more conveniently & saves more power.

?

?

under hard light ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? under weak light


Integrated dustproof front panel

FA1014-NP/C/T front panel adopts intergrated front panel, which can prevent the screen from mild droplets & dust. It also available for outdoor environment.

?


I/O control interface

The interface has functions such as connecting with reverse trigger line in car reversing system, and control computer host to switch on/off, etc. Functions also can be customized to meet different demands.

?

?

? ? ? ? ? ? ? ? ? ? ??car?reversing? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?trigger reversing image

??Display Screen ??10.1" LED IPS
??Resolution ? 1280 × 800, suport up to 1920 x 1080
??Aspect Ratio ??16:9
??Touch Panel ??Capacitive Touch (optional)
??Contrast Ratio ??800:1
??Brightness ? 350cd/㎡
??Viewing Angle ??170°/170° (H/V)
??Input Signal ??HDMI,?VGA, AV, DVI(optional)
? I/O port ??1
? Speaker ??1
??Input Voltage ??DC 7-24V
??Battery ??External (optional)
? Current ??800mA
??Power Consumption ??≤10W
??Audio Output ??≤1W
??Operating Temperature ? -0℃~50℃
??Storage Temperature ??-20℃~60℃
??Dimension(LWD) ??250×170×32.3 mm
??Weight ??560g
